[HOW TO FLASH] how to flash MK digital 1000

To flash the MK Digital XP1000 (often just referred to as the MK Digital 1000), you will follow the same procedure as the Octagon XP1000+. These boxes are “clones” or siblings of the same Broadcom architecture, and they share a very simple, reliable flashing method.

1. Preparation

• USB Stick: A high-quality USB 2.0 or 3.0 stick. Use 8GB or smaller if possible, as older Broadcom bootloaders can be picky.

• Format: The stick must be formatted to FAT32.

• Firmware: Download the image specifically for the XP1000 (OpenATV, OpenPLi, and OpenViX are popular choices).

2. Folder Structure

The receiver looks for a specific directory name on the USB root.

1. Extract the downloaded firmware zip file.

2. You will see a folder named xp1000.

3. Copy the entire xp1000 folder to the root of your USB stick.

   • Path: USB:\xp1000\

   • Contents: Inside, you should see kernel.bin, rootfs.bin, and imageversion.

3. The Flashing Process

1. Power Off: Turn off the receiver using the power switch at the back.

2. Insert USB: Plug the USB stick into the rear USB port.

3. Power On: Turn the back power switch to ON.

4. Initiate Flash: * Watch the front panel. When the device recognizes the USB, the LED will change color or start flashing (usually from red to purple/blue).

   • Quickly press the CH+ (Channel Up) button on the front panel to confirm the flash.

5. Wait: The LED will flash during the process. Do not interrupt the power.

6. Completion: Once finished, the box will reboot automatically. You can then safely remove the USB stick.

Pro-Tip for enigma2.net

Since the MK Digital 1000 and the Octagon XP1000 use the exact same folder name (xp1000), they are cross-compatible. However, for your site, I recommend advising users to stick to the specific branding of the image to ensure the remote control codes match perfectly.
