[REVIEW] TECHNOMATE TMNANOSE M2 Plus

April 5, 2026 admine2

Review: Technomate TM-NANO SE M2 Plus (The High-performance 1080p MIPS Champion)

When Technomate launched the original TM-NANO SE, it proved that compact receivers didn’t have to be sluggish. The TM-NANO SE M2 Plus (the ‘M2 Plus’ meaning the significantly updated ‘2nd Generation Plus’ Edition) is the high-performance sequel that keeps the tiny footprint but swaps out the older, single-core processor for a blazing-fast Broadcom Dual-Core chipset, making it arguably the fastest single-tuner 1080p box in its class.

We are taking an in-depth look at this “NANO” marvel on enigma2.net to see how it balances size and serious performance in a landscape of bulky receivers and cheap streaming sticks. For the hobbyist who needs speed in a bedroom or secondary room, this is the definitive compact champion.

1. Core Hardware: Blazing-Fast Broadcom Speed

The core difference between the original NANO SE and the ‘M2 Plus’ is pure processing power. Technomate didn’t just give it a minor facelift; they completely replaced the engine.

Processor (2x 750 DMIPS): The TM-NANO SE M2 Plus is powered by a blazing-fast Broadcom Dual-Core (MIPS) processor running at 2x 750 DMIPS. This is essential for handling complex plugins (like heavy IPTV players and Fast Scan) with a level of crispness that must be experienced to be appreciated.
Performance: In the Enigma2 world, this speed translates to near-instant zapping (typical sub-1 second) and a completely fluid user interface. Even heavy skins with extensive transparent layers operate with zero lag. It handles the most complex skins with zero “voodoo” software hacks.

2. PVR and Connectivity: Small Box, Big Expansion

The “NANO” label isn’t just about a compact design; it’s about smart design. The rear panel is packed with a professional array of PVR options that modern boxes have abandoned.

Internal 2.5″ SATA Bay (EASY!): The standout feature for a compact box. Despite its tiny footprint, Technomate integrated an “easy” access internal SATA bay. You can slide in an internal 2.5″ SATA hard drive, turning the NANO SE M2 Plus into a silent, professional-grade PVR without any messy external cables.
eSATA PVR & Multiple USB: For further expansion, you have a dedicated high-speed eSATA port and multiple USB 2.0 ports (1x Front, 2x Rear) for external PVR and timeshifting.
Networking: A stable 10/100Mbps Ethernet port (LAN) for IPTV plugins and fast file transfers via OpenWebif.

3. Real-World Performance: The Perfect Bedroom Box

For the enigma2.net hobbyist, the TM-NANO SE M2 Plus is the ultimate hidden gem. The compact design (approximately 200mm wide) makes it perfect for discreet placement. Thanks to the fanless architecture, it operates in complete silence.

When switching from an older HD receiver or a standard-definition box, the performance difference is staggering. Navigating through the EPG, zapping through a complex bouquet list, or launching heavy plugins feels like a true “BOOST!”. The Broadcom drivers are legendary for stability, meaning fewer crashes and fewer “voodoo” software hacks.

Technical Specifications: Technomate TM-NANO SE M2 Plus

Based on the official technical data, here is the full specification list for the receiver.

Core Processing System

CPU: Broadcom BCM7362 (Dual-Core)
Processor Speed: 2x 750 DMIPS (Total 1500 DMIPS)
RAM: 1GB DDR3
Flash Memory: 256MB NAND

Tuner and Demodulator

Tuner Type: Single Tuner Configuration (Fixed)
- Tuner 1: Fixed DVB-S2 Satellite Tuner
Frequency Range: 950 ~ 2150MHz
LNB Power & Polarization: Vertical: +13V, Horizontal: +18V, Current: Max. 500mA
DiSEqC Control: Version 1.0, 1.1, 1.2, USALS Compatible

Video and Audio

Output Resolution: 1080p Full HD (also supports 1080i, 720p, 576p, 576i)
Video Decoding: MPEG-2/H.264 (AVC) HP@L4.1, MPEG-4 Part 10
Audio Decoding: MPEG-1 Layers I, II, & III (MP3), Dolby Digital (AC-3), AAC

PVR and Expansion

Internal Storage: Internal 2.5″ SATA Hard Drive Bay (“Easy” access drawer)
External PVR: 1x eSATA Port, 3x USB 2.0 Ports (1x Front, 2x Rear)

Connectivity

Video Output: 1x HDMI 1.4, 1x Scart Output (labeled “Legacy”)
Audio Output: 1x RCA Composite Audio (L/R)
Networking: 1x 10/100Mbps Ethernet Port (LAN)
Conditional Access: 1x Internal Smart Card Reader, 1x Common Interface (CI) Slot

Physical & Power

Dimensions: Approximately 200mm x 40mm x 140mm (W x H x D)
Weight: Approximately 0.7kg
Power Supply: External 12V DC, 2A Power Adapter
Power Consumption: Max. 24W (Operational), <0.5W (Deep Standby)

Final Verdict: The Stable Single-Tuner compact Champion

The Technomate TM-NANO SE M2 Plus is a masterclass in how to build a small receiver without cutting any performance corners. It isn’t a 4K powerhouse, but for any user on enigma2.net who primarily watches 1080p content and values blazing-fast Broadcom dual-core speed (2x 750 DMIPS), silent operation, and a proper internal SATA PVR, this is arguably the best single-tuner compact ever made.

If you are looking for a reliable, expandable “hidden beast” for your bedroom or secondary room (and you don’t require 4K), the TM-NANO SE M2 Plus is, without question, WORTH IT. It’s the definition of stable, reliable performance.
